High flexible, wear resistant, Oil resistant, bending resistant, hydrolysis resistant, thermostable and cold-resistant
Sketch Map
Technical Parameter
Conductor: Ultra-fine multi-stranded bare copper wire stranded conductor(six categories)
Insulation: PP or TPE insulation mixture.
Core wire color: color differentiation or black core wire white numerical identification.
Core wire stranding: cores<12: cores twisted together at short pitch cores≥12:bundled stranding.
Outer sheath: PUR polyurethane, adjusted to meet drag chain requirements; Colors can be matched according to customer requirements.
Minimum hending radius: mobile anplication: 7.5xd: Fixed installation: 4xd.
Operating temperature range: Mobile installation:-25℃ to +85℃: Fixed installation:-50Cto+85℃.
Rated voltage: 300/500V.
Test voltage: 4000V.
Material: Customizable to suit different needs and applications with materials like PUR, PVC, TPE, TPEE, LSOH, PP, HDPE and more. From standard to specialized, we provide flexibility to meet diverse requirements. Contact us for cables solutions.
Product Characteristics
Has excellent wear resistance, bending resistance, oil resistance, and hydrolysis resistance;
Flame retardancy in accordance with IEC 60332-1-2, CEI 20-35, FT1, VW-1;
Designed for bending cycles up to 10 million or more in power drag chains.
Application Scope
Used for power drag chains or moving mechanical components;
Especially suitable for damp areas of machine tools and transmission lines;
Used for measuring, controlling, and regulating circuits;
Power circuits used in automation engineering electrical equipment;
Used in dry or humid indoor environments with high mechanical loads.
Product Standards
| Material code | Number of cores and nominal cross-section of conductor(mm²) | Approximate outer diameter(mm²) | Cable weight kg/km |
| FD-800P-2-0.5 | 2x0.5 | 5.3 | 36 |
| FD-800P-3-0.5 | 3x0.5 | 5.7 | 44 |
| FD-800P-4-0.5 | 4x0.5 | 6.3 | 54 |
| FD-800P-5-0.5 | 5x0.5 | 6.8 | 63 |
| FD-800P-7-0.5 | 7x0.5 | 8.0 | 84 |
| FD-800P-12-0.5 | 12x0.5 | 9.5 | 132 |
| FD-800P-18-0.5 | 18x0.5 | 11.8 | 181 |
| FD-800P-25-0.5 | 25x0.5 | 13.5 | 246 |
| FD-800P-30-0.5 | 30x0.5 | 14.3 | 286 |
| FD-800P-34-0.5 | 34x0.5 | 15.6 | 336 |
| FD-800P-50-0.5 | 50x0.5 | 18.5 | 496 |
| FD-800P-2-0.75 | 2x0.75 | 5.7 | 45 |
| FD-800P-3-0.75 | 3x0.75 | 6.2 | 56 |
| FD-800P-4-0.75 | 4x0.75 | 6.8 | 66 |
| FD-800P-5-0.75 | 5x0.75 | 7.4 | 80 |
| FD-800P-7-0.75 | 7x0.75 | 8.9 | 106 |
| FD-800P-12-0.75 | 12x0.75 | 10.6 | 169 |
| FD-800P-18-0.75 | 18x0.75 | 12.7 | 255 |
| FD-800P-25-0.75 | 25x0.75 | 15.2 | 359 |
| FD-800P-2-1.0 | 2x1.0 | 6.1 | 54 |
| FD-800P-3-1.0 | 3x1.0 | 6.6 | 68 |
| FD-800P-4-1.0 | 4x1.0 | 7.3 | 84 |
| FD-800P-5-1.0 | 5x1.0 | 8.0 | 100 |
| FD-800P-7-1.0 | 7x1.0 | 9.6 | 138 |
| FD-800P-12-1.0 | 12x1.0 | 11.4 | 213 |
| FD-800P-14-1.0 | 14x1.0 | 12.3 | 254 |
| FD-800P-16-1.0 | 16x1.0 | 13 | 283 |
| FD-800P-18-1.0 | 18x1.0 | 13.9 | 320 |
| FD-800P-25-1.0 | 25x1.0 | 16.4 | 441 |
| FD-800P-41-1.0 | 41x1.0 | 20.6 | 708 |
| FD-800P-50-1.0 | 50x1.0 | 22.3 | 850 |
| Material code | Number of cores and nominal cross-section of conductor(mm²) | Approximate outer diameter(mm²) | Cable weight kg/km |
| FD-800P-2-1.5 | 2x1.5 | 7.7 | 79 |
| FD-800P-3-1.5 | 3x1.5 | 8.2 | 102 |
| FD-800P-4-1.5 | 4x1.5 | 9 | 127 |
| FD-800P-5-1.5 | 5x1.5 | 9.8 | 162 |
| FD-800P-7-1.5 | 7x1.5 | 11.0 | 199 |
| FD-800P-12-1.5 | 12x1.5 | 15 | 323 |
| FD-800P-18-1.5 | 18x1.5 | 18 | 461 |
| FD-800P-25-1.5 | 25x1.5 | 21 | 658 |
| FD-800P-2-2.5 | 2x2.5 | 9.2 | 109 |
| FD-800P-3-2.5 | 3x2.5 | 10 | 141 |
| FD-800P-4-2.5 | 4x2.5 | 10.8 | 186 |
| FD-800P-5-2.5 | 5x2.5 | 12 | 224 |
| FD-800P-7-2.5 | 7x2.5 | 14.2 | 307 |
| FD-800P-12-2.5 | 12x2.5 | 18.5 | 482 |
| FD-800P-18-2.5 | 18x2.5 | 23 | 739 |
| FD-800P-25-2.5 | 25x2.5 | 25 | 967 |
| FD-800P-3-4.0 | 3x4.0 | 11 | 194 |
| FD-800P-4-4.0 | 4x4.0 | 12.3 | 256 |
| FD-800P-5-4.0 | 5x4.0 | 13.8 | 321 |
| FD-800P-4-6.0 | 4x6.0 | 14.5 | 369 |
| FD-800P-5-6.0 | 5x6.0 | 16 | 454 |
| FD-800P-4-10.0 | 4x10.0 | 18.2 | 588 |
| FD-800P-5-10.0 | 5x10.0 | 20.6 | 758 |
| FD-800P-4-16.0 | 4x16.0 | 21.5 | 896 |
| FD-800P-5-16.0 | 5x16.0 | 24.5 | 1115 |
| FD-800P-4-25.0 | 4x25.0 | 28.5 | 1441 |
| FD-800P-4-35.0 | 4x35.0 | 31 | 1890 |
