Conductor: super-fine strands of bare copper wire or tinned copper wire stranded conductor.
Technical Parameters
Conductor: super-fine strands of bare copper wire or tinned copper wire stranded conductor.
Insulation: PP insulation mixture.
Core wire color: color differentiation
Twisted pair: The optimal pitch is twisted in pairs.
Twisting: Twisting at the optimal short pitch.
Shielding: silvered or tinned copper wire braid shielding, optical coverage of about 80%.
Outer sheath :TPU polyether, adjusted to meet the requirements of the towline; Colors can be customized according to customer requirements.
Operating temperature range: occasional movement :-20C to +80C; Fixed installation :-40C to +80C.
Rated voltage: 300v.
Test voltage: 500V.
Material: Customizable to suit different needs and applications with materials like PUR, PVC, TPE, TPEE, LSOH, PP, HDPE and more. From standard to specialized, we provide flexibility to meet diverse requirements. Contact us for cables solutions.
Product Characteristics
Flame retardant, oil resistance, acid and alkali resistance, low temperature resistance, UV resistance, wear resistance, hydrolysis resistance, etc.
Application Scope
Used in CNC machine tools, production lines, logistics systems, robots, etc.;
Used in processing equipment, cranes, production lines, etc.
Our products have a wide range of applications and guaranteed quality
