High flexible, wear resistant, Oil resistant, bending resistant, hydrolysis resistant, thermostable and cold-resistant
Sketch Map
Technical Parameter
Conductor: Ultrafine stranded bare copper wire stranded conductor (sixcategories).
Insulation: PP or TPE insulation mixture.
Core wire color: color differentiation or black core wire white numerical identification.
Core wire stranding: cores less than twelve: cores twisted together at short pitch, cores greater than or equal to twelve: bundled stranding.
Shielding layer: Tinned copper wire woven shielding optical coverage of about 85%.
Outer sheath: PUR polyurethane, adjusted to meet drag chain requirements; Colors can be matched according to customer requirements.
Minimum bending radius: mobile application: 8xd;Fixed installation: 5xd.
Operating temperature range: Mobile installation:-20℃to+80℃; Fixed installation:-40℃ to+80℃.
Rated voltage: The number of cores is less than twelve:300/500V Core count less than twelve(0.25-0.34);300/300V.
Number of cores greater than or equal to twelve:300/300V.
Test voltage: 4000V.
Material: Customizable to suit different needs and applications with materials like PUR, PVC, TPE, TPEE, LSOH, PP, HDPE and more. From standard to specialized, we provide flexibility to meet diverse requirements. Contact us for cables solutions.
Product Characteristics
Has excellent wear resistance, bending resistance, and oil resistance;
Flame retardancy in accordance with IEC 60332-1-2CEI 20-35 VW-1;
Designed for bending cycles up to 10 million or more in power drag chains.
Application Scope
Used for moving in automatic machine drag: chains:
Used in mechanical processing, wood/stone processing industry, packaging industry, conveving svstems, and regulating equipment drag chains;
Mainly used indoors.
Product Standards
| Material code | Number of cores and nominal cross-section of conductor(mm²) | Approximate outer diameter(mm²) | Cable weight kg/km |
| FD-800CP-2-0.5 | 2x0.5 | 5.8 | 42 |
| FD-800CP-3-0.5 | 3x0.5 | 6.2 | 56 |
| FD-800CP-4-0.5 | 4x0.5 | 6.8 | 80 |
| FD-800CP-5-0.5 | 5x0.5 | 7.3 | 93 |
| FD-800CP-7-0.5 | 7x0.5 | 8.6 | 133 |
| FD-800CP-12-0.5 | 12x0.5 | 10.1 | 197 |
| FD-800CP-18-0.5 | 18x0.5 | 12.4 | 272 |
| FD-800CP-25-0.5 | 25x0.5 | 14.1 | 347 |
| FD-800CP-30-0.5 | 30x0.5 | 15 | 422 |
| FD-800CP-2-0.75 | 2x0.75 | 6.8 | 53 |
| FD-800CP-3-0.75 | 3x0.75 | 7.5 | 67 |
| FD-800CP-4-0.75 | 4x0.75 | 8 | 403 |
| FD-800CP-5-0.75 | 5x0.75 | 8.6 | 122 |
| FD-800CP-7-0.75 | 7x0.75 | 10.0 | 157 |
| FD-800CP-12-0.75 | 12x0.75 | 12.4 | 237 |
| FD-800CP-18-0.75 | 18x0.75 | 14.9 | 357 |
| FD-800CP-25-0.75 | 25x0.75 | 17.4 | 485 |
| FD-800CP-2-1.0 | 2x1.0 | 7.0 | 87 |
| FD-800CP-3-1.0 | 3x1.0 | 7.7 | 107 |
| FD-800CP-4-1.0 | 4x1.0 | 8.5 | 119 |
| FD-800CP-5-1.0 | 5x1.0 | 9.3 | 143 |
| FD-800CP-7-1.0 | 7x1.0 | 11.0 | 189 |
| FD-800CP-12-1.0 | 12x1.0 | 13.5 | 269 |
| FD-800CP-14-1.0 | 14x1.0 | 14.5 | 303 |
| FD-800CP-16-1.0 | 16x1.0 | 15.2 | 345 |
| FD-800CP-18-1.0 | 18x1.0 | 16 | 385 |
| FD-800CP-25-1.0 | 25x1.0 | 18.5 | 549 |
| FD-800CP-41-1.0 | 41x1.0 | 22 | 857 |
| FD-800CP-50-1.0 | 50x1.0 | 24.2 | 990 |
| Material code | Number of cores and nominal cross-section of conductor(mm²) | Approximate outer diameter(mm²) | Cable weight kg/km |
| FD-800CP-2-1.5 | 2x1.5 | 8.4 | 109 |
| FD-800CP-3-1.5 | 3x1.5 | 9 | 130 |
| FD-800CP-4-1.5 | 4x1.5 | 9.9 | 159 |
| FD-800CP-5-1.5 | 5x1.5 | 10.9 | 189 |
| FD-800CP-7-1.5 | 7x1.5 | 12.7 | 253 |
| FD-800CP-12-1.5 | 12x1.5 | 15.8 | 395 |
| FD-800CP-18-1.5 | 18x1.5 | 18.9 | 550 |
| FD-800CP-25-1.5 | 25x1.5 | 22.0 | 785 |
| FD-800CP-2-2.5 | 2x2.5 | 9.8 | 138 |
| FD-800CP-3-2.5 | 3x2.5 | 10.6 | 189 |
| FD-800CP-4-2.5 | 4x2.5 | 11.5 | 235 |
| FD-800CP-5-2.5 | 5x2.5 | 12.8 | 293 |
| FD-800CP-7-2.5 | 7x2.5 | 15.3 | 379 |
| FD-800CP-12-2.5 | 12x2.5 | 20.3 | 636 |
| FD-800CP-4-4.0 | 4x4.0 | 13.3 | 315 |
| FD-800CP-4-6.0 | 4x6.0 | 15.8 | 463 |
| FD-800CP-4-10.0 | 4x10.0 | 19.5 | 719 |
| FD-800CP-4-16.0 | 4x16.0 | 23.2 | 1049 |
| FD-800CP-4-25.0 | 4x25.0 | 29.8 | 1447 |
| FD-800CP-4-35.0 | 4x35.0 | 32.5 | 2163 |
Our products have a wide range of applications and guaranteed quality
